| Callout # |
Part Number |
Description |
Notes |
| 1 |
Endcap-Mtg-Tube-LH |
Left Hand Endcap and Mounting Tube Assembly |
|
| 2 |
R001903--- |
Left Hand Endcap |
|
| 3 |
Endcap-Mtg-Tube-RH |
Right Hand Endcap and Mounting Tube Assembly |
|
| 4 |
R001904--- |
Right Hand Endcap |
|
| 5 |
R001902--- |
Plug |
|
| 6 |
SG0027---- |
Roller Support Cradle |
|
| 7 |
610900---- |
Roller Tube |
|
| 8 |
R012019---- |
Left Hand Spindle Assembly |
|
| 9 |
R001859-- |
Right Hand Spring Assembly |
|
| 10 |
R041481-001 |
Spring Sleeve (for single slot roller tube) |
|
| 11 |
R012546---- |
Tall Bracket Mounting Kit |
|
| 12 |
R012545---- |
Short Bracket Mounting Kit |
|
| 13 |
610700---- |
Awning Rail |
|
| 16 |
BX0013-2---- |
Carefree Slide Topper Prepped Access Plate Adapter Kit |
|
| The following parts are not displayed in the diagram above. |
| 14 |
R001925---- |
Standard Hardware Pack |
|
| 15 |
R001926---- |
XL Hardware Pack |
|
