How to Replace LED Strip Lights on Your RV Awning: A Setup Guide
There is nothing quite like winding down after a day on the road at a campsite under the stars. Replacing LED strip lights on your RV awning or vehicle is an easy, high-impact upgrade that adds safety, style and comfort to your outdoor experience. With Carefree’s adhesive-backed LED light strips, the transformation is simple and the possibilities are endless. Use this step-by-step guide to replace LED lights on your RV like a professional.
Why Add LED Strip Lights to Your RV Awning?
LED awning lights aren’t just for show. They enhance your outdoor living space by:
Creating a warm, inviting atmosphere for nighttime hangouts
Providing better visibility when cooking, entertaining, or walking outside
Deterring pests and improving campsite security
Reducing power usage compared to traditional bulbs
LED light strips at Carefree are specifically designed for RVs, with flexible mounting options and smart power adaptability for 110V or 12Vdc systems.
Carefree LED Features
Not all LED strips are created equal. Choose LED lights that are:
Adhesive-backed for easy surface mounting
Cut-to-length to fit your awning or sidewall precisely
If you are wiring the LED lights into your vehicle’s 12Vdc power source, you’ll need the following tools:
Universal Color LED Light Kit™ or Universal White LED Light Kit™
Power drill with 9/16 inch bit
Screwdriver
Crimping pliers
Inline fuse and fuse holder
18 AWG wire (minimum)
Waterproof connectors or heat shrink tubing
Mounting surface cleaner
12V DC power source or 110V AC outlet
Safety Tips Before Installing or Replacing LED Awning Lights
Avoiding Short Circuits and Overloads
Double-check all wiring connections before powering up. Avoid mixing up positive and negative leads, and never connect LED strips directly to power without a fuse.
Using Fuses and Proper Gauge Wiring
Always use a properly rated inline fuse between your power source and the LED strip. Shade Company recommends a minimum 18-gauge wire for both power and ground connections.
Working with 12V Systems Safely
Disconnect your RV’s battery before wiring into the 12V system. If you’re not comfortable with electrical work, consider hiring a professional or consulting your RV dealer.
Step-by-Step Guide to Replacing LED Lights on Your RV Awning
Plan Your Installation Location
Decide where you want to replace or install the light strip. Popular spots include just beneath the awning rail or on the RV wall under the awning arm. Make sure the surface is clean, dry, and within reach of your power source.
Prepare the Mounting Surface
Wipe the area clean with alcohol or a degreaser to remove dust and oils. This will help the adhesive bond securely to the RV’s surface.
Mount the LED Strip
For adhesive-backed LED strips:
Peel off the protective liner from the back of the strip
Press the strip firmly into place as you go, starting from one end
Apply steady pressure to secure the bond
For Installations: Wire the LED Strip to Your RV’s 12V System
You can power your lights using either your RV’s 12V system or a standard 110V outlet.
Choose a location for the exterior 12V receptacle. Make sure it is easy to access and not in the way of doors or walkways
Drill a 9/16 inch hole at the chosen mounting point
Insert the receptacle through the hole from the inside and secure it with the supplied nut
Route the receptacle wires to a 12V power source and ground inside your RV. The positive wire is marked (+) and the ground wire is marked (–)
Splice the wires using waterproof connectors or crimp splices
Cut the power wire and install the inline fuse. Use pliers to close the connector securely
Slide the fuse into the holder and ensure it is seated correctly
Test the System and Secure All Components
Reconnect the power and test the lights. If they don’t turn on, check your wiring and fuses. Once verified, tidy up excess wiring with clips or zip ties and seal any entry points with silicone.
Replacing an Existing RV Awning Light Strip
How to Remove the Old Strip
Gently peel back the old strip. Use a plastic scraper if needed. Remove any leftover adhesive with alcohol or adhesive remover. Disconnect any attached wiring and inspect for damage.
Installing the Replacement LED Strip
Install the new LED strip following the same steps listed above. Carefree LED strips are cuttable for custom lengths, so replacing only the portion you need is fast and easy.
Troubleshooting Common LED Awning Light Issues
Why Are My RV Awning Lights Flickering?
Check for loose connections, weak battery voltage, or a failing LED strip. Confirm that your fuse is secure and that no wires are exposed or corroded.
What If My Light Strip Is Too Long?
LED strips are marked with cut points. Trim the strip only at those points, then seal the ends with silicone to protect against moisture.
Can I Use My Existing Porch Light Switch?
If your porch light is already wired to 12V, you may be able to connect your LED strip to that same circuit. This allows you to control both from one switch, though professional guidance is recommended for system integration.
Remote LED Controls
Carefree LED kits come with a water-resistant, wireless, radio frequency remote control. The Universal Color LED Light Kit’s remote features a color dial for easy adjustments on the go.
Hit the Road in Style
Installing LED strip lights on your RV awning is one of the easiest ways to add comfort, character, and capability to your outdoor space. With Carefree’s high-performance, adhesive-mounted LED systems, it takes just a few tools and a little planning to transform your setup into something spectacular. Whether you power through your 12V system or plug into 110V, you’ll enjoy evenings outside like never before. Explore our product line today.
FAQ
How Do You Attach Replacement LED Lights to a Camper Awning?
Clean the surface, peel off the adhesive backing, and press the LED strip firmly in place along the awning housing or wall.
Can I Install Lights Without a Track?
Yes. Carefree LED strips are adhesive-backed and designed to install directly on most clean, flat surfaces.
How Do I Seal the Installation to Prevent Water Damage?
Use silicone at connection points and the ends of the LED strip. Waterproof connectors are also a good option for exposed wiring.
What’s the Best Wire Gauge for LED Lights?
Use 18 AWG wire or heavier for 12V installations to ensure safe power delivery without overheating.
